Photovoltaic Module TRIxxxHP-WB MWT 126 half-cut cells

Industrial

Photovoltaic Module TRIxxxHP-WB MWT 126 half-cut cells

  ACCESS THE CONFIGURATOR

The Trienergia TRIxxxHP-WB 126 half-cell modules are latest generation photovoltaic panels, with high performance and a high aesthetic impact thanks to the black and white colour. Ideal for residential photovoltaic systems installed on prestigious or industrial properties, in areas that want to maintain a high aesthetic and landscape sense.

Design

Ideal for installations with high aesthetic value.

Guaranteed

Product guaranteed for 20 years.

High performance

12-year 90% performance guarantee.

Technical information

TRIxxxHP-WB
Ideal for systems with high aesthetic value


126 HALF CELLS M6 - 166.00 x 83.00 mm
Photovoltaic Module MonoPERC MWT with Backcontact Conductive Backsheet
Dimensions 1805 x 1035 x 30 mm
Weight 20.50 kg
Backsheet color WHITE
BLACK anodized aluminium frame
Central JunctionBox
Compatible MC4 connectors
Product warranty: 20 years*
Performance guarantee: 12 years at 90% |  30 years at 82%
Certificates: IEC 61215 – IEC 61730 – IEC 61701 – IEC 61716 - FIRECLASS 1

*25 Years warranty only for Green Specialist GOLD installers

Additional Information

Trienergia TRIxxxHP-WB, M6 half-cell photovoltaic panels, innovative and with high power. Ideal for industrial plants

These innovative solar panels are produced in the Trienergia plant in Bondeno di Gonzaga (Mantua) using all the latest generation technologies.

The cells are made of monocrystalline silicon with PERC (Passivated Emitter and Rear Cell) technology. The photovoltaic panels are black, with a black aluminum frame and white backsheet. The total size of the module is 1805 x 1035 x 30 mm.

The half-cell modules are equipped with MWT (Metal Wrap Through) backcontacts with electrodes positioned in the rear part of the module and with cells without welding as they are no longer soldered at the connection points but glued onto an innovative conductive backsheet. This allows for an increase in efficiency of approximately 20% compared to standard panels, and a lower risk of breakages and microfractures. Thanks to the backsheet, there is also an optimization of performance in the event of partial shading, as the power of the entire string of cells is not lost, but only of the darkened ones.

Thanks to the possibility of producing a higher power, Trienergia TRIxxxHP-WB panels are ideal for installation in industrial photovoltaic systems, for example on warehouses, roofs or on the roofs of buildings for industrial use.

The return guarantee is 90% after 12 years and 82% after 30 years.

The sale is aimed mainly at designers, installers and wholesalers of photovoltaic material.

To find out the list prices, simply request a free quote via the appropriate form on this sheet.
