The Trienergia modules of the TRIxxxDP-BB GREEN line are designer and high-efficiency photovoltaic solar panels, designed for those looking for, in addition to energy efficiency, an aesthetically valid product for their residential system.

Technical information

TRIxxxDP-GG Rectangular – GREEN
Ideal for systems with high aesthetic value

42 M6 CELLS - (166 x 166mm)

MonoPERC MWT Photovoltaic Module with Backcontact Conductive Backsheet

Dimensions 1211 x 1035 x 35 mm

Weight 14.0kg

Full black color

Black aluminum frame

Central JunctionBox

Compatible MC4 connectors

Product warranty: 20 years*

Performance guarantee: 12 years at 90% |  30 years at 82%

Certificates: IEC 61215 – IEC 61730 – IEC 61701 – FIRECLASS 1

*25 Years warranty only for Green Specialist GOLD installers

Additional Information

Trienergia TRIxxxDP-GG 42 M6 cells, green photovoltaic panels with a modern design for systems on luxury homes in landscape-restricted areas

Thanks to the total-green look (green photovoltaic cells and green anodized aluminum frame) and the great aesthetic impact, they can increase the value of the home on which they are installed, be it a villa, a small house or a luxury home. The RAL 6007 green color (bottle green or bottle green) makes them ideal for camouflage and best integrate into homes with green roofs or located in areas subject to certain historical or landscape constraints.

Thanks to the modular solution of the Trienergia Energy Design system, these 42-cell modules can be combined with the other triangular 21-cell and rectangular 60-cell green photovoltaic panels to cover a greater surface area on triangular and trapezoidal pitched roofs, in an aesthetically harmonious way, and above all without having to give up high performance and high energy efficiency. For this reason they are highly appreciated by designers of residential photovoltaic systems who must respect landscape constraints in the specifications.

Trienergia is a manufacturer of latest generation photovoltaic panels. All panels produced in the Trienergia factory in the province of Mantua, taking advantage of the latest technological innovations in the photovoltaic sector.

The new back-contact MWT (Metal Wrap Through) technology allows you to have the electrodes in the back part of the modules, and to have no welding at the connection points between the photovoltaic cells, as these are glued onto a special conductive backsheet (EBfoil ® BYS). In this way, the risks of breakage and microfractures are reduced to a minimum and a higher yield is also obtained (approximately 20% more than standard modules) and integrated optimization in the case of partial shading.

Each green photovoltaic panel is made up of 42 M6 cells (166 x 166mm) in monocrystalline silicon with PERC (Passivated Emitter and Rear Cell) technology, and can be used for grid connected photovoltaic systems.

The available model, with characteristics and peak powers:

TRI230DP-GG (nominal power 230 Wp)

For all specifications, consult the datasheet which can be downloaded for free in the “Download” section of this page.

The product guarantee is 20 years (increased to 25 years for Green Specialist Gold installers), while the performance guarantee is 90% after 12 years and 82% after 30 years.

The sale is mainly aimed at designers, installers and wholesalers of photovoltaic material.

To find out costs and prices, simply request a free quote without obligation using the appropriate form on this page.
