Photovoltaic Module TRIxxxTP-GG MWT 21 cells (triangular) GREEN


Photovoltaic Module TRIxxxTP-GG MWT 21 cells (triangular) GREEN


The Trienergia TRIxxxTP-GG GREEN modules are triangular-shaped photovoltaic panels, colored in green (RAL 6007 bottle green). These green-colored solar panels have a modern and eye-catching design and can seamlessly integrate with the roofs of villas and residential buildings, for example, in homes with green roofs or located in areas subject to historical and landscape constraints.

Technical information

TRIxxxTP-GG Triangular - GREEN

Ideal for installations with high aesthetic value

  • 21 CELLS M6 - 166x166 mm
  • MonoPERC MWT Photovoltaic Module with Backcontact Conductive Backsheet
  • Dimensions: 1035 x 1035 x 35 mm
  • Weight: 7.0 kg
  • Green color
  • Green aluminium frame
  • Central Junction Box
  • Compatible MC4 connectors
  • Product Warranty: 20 years*
  • Performance Warranty: 12 years at 90% | 30 years at 82%
  • Certifications: IEC 61215 – IEC 61730 – IEC 61701 – FIRECLASS 1

*25-year warranty only for Green Specialist GOLD installers

Additional Information

The production process, completely automatic, provides:
  1. Positioning of the conductive backsheet made with EBfoil® BYS, which acts as a contact and connection for the positive / negative contacts on the back of the solar panel
  2. Laying of the cells that make up the photovoltaic module: these are glued on the backsheet by the silk-screen dispensing of a special conductive glue; at the same time a quality control is performed on the cells:
    – Chipping: chipping on the edge of the cell
    – Breakage: cell breakage
    – Microcrack: cell micro-perforation not visible to the naked eye
    – Positioning: positioning of the cell
  3. Application of an EVA (ethylene vinyl acetate) sheet, very flexible and elastic, which encapsulates the cells with the backsheet
  4. Glass application
  5. Flipping, rotation of the module to enter lamination resting on the glass
  6. Panel lamination
  7. Framing, assembly of the frame
  8. Tests: solar simulator and electroluminescence
Available models:
  • TRI115TP-GG
