Photovoltaic Module TRIxxxTP-BB MWT 21 cells (triangular) BLACK


Photovoltaic Module TRIxxxTP-BB MWT 21 cells (triangular) BLACK


The Trienergia photovoltaic modules of the TRIxxxTP-BB series are high-performance and high-efficiency "triangular" solar panels, especially suitable for installation on triangular pitched roofs. In the FULL BLACK version, they are ideal for those who pay particular attention to the design of their home.


Ideal for installations with high aesthetic value.


Product guaranteed for 20 years.

High performance

12-year 90% performance guarantee.

Technical information

TRIxxxTP-BB Triangular

BLACK Ideal for installations with high aesthetic value

  • 21 CELLE M6 - 166x166 mm
  • MonoPERC MWT Photovoltaic Module with Backcontact Conductive Backsheet
  • Dimensions: 1035 x 1035 x 35 mm
  • Weight: 7.0 kg
  • Black Backsheet Black aluminium frame
  • Central Junction Box
  • Compatible MC4 connectors
  • Product Warranty: 20 years*
  • Performance Warranty: 12 years at 90% | 30 years at 82%
  • Certifications: IEC 61215 – IEC 61730 – IEC 61701 – FIRECLASS 1

*25-year warranty only for Green Specialist GOLD installers

Additional Information

TRIENERGIA TRIXXXTP-BB, full black triangular photovoltaic panels for high-end residential installations.

The TRIENERGIA TRIXXXTP-BB are design photovoltaic modules, black (both the photovoltaic cells and the backsheet are black, for a total black look), designed to seamlessly integrate with the design of the house without compromising aesthetics, and without sacrificing energy efficiency.

The panels are assembled at the Trienergia plant in Mantua using state-of-the-art technologies in the photovoltaic industry. Thanks to the back-contact MWT technology (Metal Wrap Through, with electrodes on the back of the module), the cells are no longer soldered at the connection points but glued to a special conductive backsheet. Without soldering, there is an increase in efficiency (they are about 20% more efficient than standard panels) and a limitation of the risks of breakage and microfractures.

In addition to high performance, the strength of these new triangular solar panels lies in their design and triangular shape. Trienergia has decided to provide a modular solution that allows for aesthetically harmonious coverage of triangular-shaped roofs, with a combination of triangular photovoltaic modules (21 cells) and rectangular ones (42 or 60 cells). This is the innovative Energy Design (Trienergia Energy Design).

Each triangular photovoltaic module consists of 21 monocrystalline silicon cells with PERC technology (Passivated Emitter and Rear Cell) and is suitable for grid-connected PV installations, i.e., connected to the electrical grid.

Available power ratings and panel specifications can be found in the datasheet available in the Download section of this page.

  • TRI125TP-BB (rated power 125 Wp)
    The durability over time is guaranteed (90% efficiency after 12 years and 82% after 30 years).

Sales are mainly aimed at installers and wholesalers of photovoltaic materials. These modules are also an excellent solution for designers who often face landscape constraints. Thanks to the modular system, there is greater freedom in the design of the photovoltaic system, with a significant aesthetic impact, capable of enhancing the value of the residence.

To know the prices, simply request a free quote through the appropriate form on this page.
