Photovoltaic Module TRIxxxDP-BB MWT 42 cells BLACK

Residential

Photovoltaic Module TRIxxxDP-BB MWT 42 cells BLACK

  ACCESS THE CONFIGURATOR

The Trienergia photovoltaic modules of the TRIxxxDP-BB series are high-performance and high-efficiency solar panels, especially suitable for installation on triangular pitched roofs. In the FULL BLACK version, they are ideal for those who pay particular attention to the design of their home.

Design

Ideal for installations with high aesthetic value.

Guaranteed

Product guaranteed for 20 years.

High performance

12-year 90% performance guarantee.

Technical information

TRIxxxDP-BB RED

Ideal for installations with high aesthetic value

  • 42 CELLS M6 - 166x166 mm
  • MonoPERC MWT photovoltaic module with Backcontact Conductive Backsheet
  • Dimensions: 1211 x 1035 x 35 mm
  • Weight: 14.0 kg
  • Full Black color
  • Black aluminum frame
  • Central junction box MC4 compatible connectors
  • Product warranty: 20 years*
  • Performance warranty: 12 years at 90% | 30 years at 82%
  • Certifications: IEC 61215 – IEC 61730 – IEC 61701 – FIRECLASS 1

*25 years warranty only for Green Specialist GOLD installers

Additional Information

Trienergia TRIxxxDP-BB 42-cell M6, modern full black solar panels for installations on high-end homes

They are design-oriented photovoltaic full black modules (both the photovoltaic cells and the backsheet are black, giving a total black look), designed to integrate seamlessly with the house's design without compromising aesthetics or energy efficiency.

They are designed for use with full black triangular photovoltaic panels on triangular and trapezoidal roofs. Thanks to the modular solution of the Trienergia Energy Design system, the 42- and 60-cell rectangular modules can be combined with the 21-cell triangular modules to cover a larger portion of the roof harmoniously, while maintaining high performance and energy efficiency. This provides greater flexibility in the design of domestic photovoltaic systems and is highly appreciated by designers who must adhere to landscape restrictions.

These solar panels are assembled at Trienergia's facility in Mantua, using all the latest photovoltaic technologies.

The new back-contact MWT (Metal Wrap Through) technology places electrodes on the back of the modules, and the photovoltaic cells have no soldering at connection points as they are glued to a conductive backsheet, minimizing the risks of breakage and micro-cracks while providing higher performance (up to 20% more than standard modules). Additionally, since the cells are glued individually to the backsheet and no longer connected to each other with ribbons, integrated optimization is achieved in case of partial shading. If only part of the panel is shaded, only the power of the shaded cells is lost, while the performance of a significant portion of the module is preserved.

Each photovoltaic module consists of 42 M6 cells (166 x 166 mm) of monocrystalline silicon with PERC (Passivated Emitter and Rear Cell) technology and is suitable for grid-connected photovoltaic systems.

The available model, with specifications and peak power:

  • TRI230DP-BB (nominal power 230 Wp)

For all specifications, refer to the free downloadable datasheet available in the "Download" section of this page.

The performance warranty is 90% after 12 years and 82% after 30 years.

The sale primarily targets designers, installers, and wholesalers of photovoltaic materials.

To find out costs and prices, request a free, no-obligation quote using the form on this page.
