Photovoltaic Module TRIxxxDP-RR MWT 42 cells RED


Photovoltaic Module TRIxxxDP-RR MWT 42 cells RED


Trienergia's TRIxxxDP-RR RED series modules are high-efficiency, design-oriented solar panels tailored for those who seek not only energy efficiency but also an aesthetically pleasing product for their residential installations. They are ideal for domestic installations in areas with historical and landscape constraints.


Ideal for installations with high aesthetic value.


Product guaranteed for 20 years.

High performance

12-year 90% performance guarantee.

Technical information


Ideal for installations with high aesthetic value

  • 42 CELLS M6 - 166x166 mm
  • MonoPERC MWT photovoltaic module with Backcontact Conductive Backsheet
  • Dimensions: 1211 x 1035 x 35 mm
  • Weight: 14.0 kg
  • Red color
  • Red aluminum frame
  • Central junction box MC4 compatible connectors
  • Product warranty: 20 years*
  • Performance warranty: 12 years at 90% | 30 years at 82%
  • Certifications: IEC 61215 – IEC 61730 – IEC 61701 – FIRECLASS 1

*25 years warranty only for Green Specialist GOLD installers

Additional Information

Trienergia TRIxxxDP-RR 42-cell M6, modern red solar panels for installations on high-end homes in historically protected areas

With a total-red look and high aesthetic impact, these panels can enhance the value of the property (villa, cottage, or high-end house) on which they are installed. The brick red color (RAL 8015) allows them to blend seamlessly with red roof tiles, making them particularly suitable for historic centers and areas subject to specific landscape or historical constraints.

Designed for use with red triangular photovoltaic panels on triangular and trapezoidal roofs. Thanks to the modular solution of the Trienergia Energy Design system, the 42- and 60-cell rectangular modules can be combined with the 21-cell triangular modules to cover a larger roof area harmoniously while maintaining high performance and energy efficiency. This provides more flexibility in the design of domestic photovoltaic systems and is highly valued by designers who need to adhere to landscape restrictions.

These solar panels are assembled at Trienergia's facility in Mantua, using the latest photovoltaic technologies.

The new back-contact MWT (Metal Wrap Through) technology places electrodes on the back of the modules. Additionally, the photovoltaic cells have no soldering at connection points, as they are glued to a conductive backsheet, minimizing the risks of breakage and microcracks while providing higher performance (up to 20% more than standard modules). Furthermore, since the cells are glued individually to the backsheet and no longer interconnected with ribbons, integrated optimization is achieved in case of partial shading. If there is shadow on only part of the panel, only the shaded cells lose power, while the performance of the rest of the module is preserved.

Each red photovoltaic module consists of 42 M6 cells (166 x 166mm) made of monocrystalline silicon with PERC (Passivated Emitter and Rear Cell) technology and is suitable for grid-connected photovoltaic systems.

The available model, with specifications and peak power:

  • TRI230DP-RR (nominal power 230 Wp)
    For all specifications, refer to the downloadable datasheet available in the "Download" section of this page.

The performance warranty is 90% after 12 years and 82% after 30 years.

The sale primarily targets designers, installers, and wholesalers of photovoltaic materials.

To know costs and prices, request a free quote without obligation using the appropriate form on this page.
