The Trienergia COE-XXXM10EF PV module is a photovoltaic panel dedicated to the revamping of modules with EU factory inspection request.
Ideal for installations with high aesthetic value.
Product guaranteed for 20 years.
12-year 90% performance guarantee.
COE-XXXM10EF
Ideal for EU revamping systems
108 HALF CELLS M10 HC – 182 x 91 mm
Rectangular PERC monocrystalline photovoltaic modules
Dimensions: 1724 x 1136 x 36 mm (height x width x depth)
Weight: 20.20 kg
Backsheet color white
Black anodized aluminum frame
Compatible MC4 connectors
Product warranty: 15 years
Performance guarantee: 12 years at 90% – 25 years at 80%
Certificates: IEC 61215, IEC 61730, FIRECLASS 1
*25 Years warranty only for Green Specialist GOLD installers
108 half-cell photovoltaic panels, ideal for replacing modules on existing systems and which must have specific certifications for EU revamping.
The available model, with characteristics and peak powers:
COE-425M10EF: nominal power 425 Wp
COE-430M10EF: nominal power 430 Wp
For all specifications, consult the datasheet which can be downloaded for free in the “Download” section of this page.
In terms of performance, 90% efficiency is guaranteed for up to 12 years and 80% for up to 25 years of use.
The sale of these photovoltaic modules is mainly aimed at installers, designers and wholesalers. To find out the cost, simply request a free quote by filling out the form in the "Request a free quote" panel.
